Roland CUBE 60W Bass Amplifier CB-60XL

XL Power for Bassists!

Just as the CUBE guitar-amp family received an XL upgrade, now it’s time for the CUBE BASS line to reach XL status. The new CUBE XL BASS amplifiers remain portable and travel friendly, a CUBE tradition, but they benefit from new-generation XL performance enhancements. These new amps deliver a knock-out punch with custom FFP and COSM technology. FFP is one of Roland’s core technologies in which each component — amp, cabinet, and speaker — achieves maximum efficiency and performance for incredible power from a compact body.

The mid-size CUBE-60XL BASS provides 60 watts of power in a portable cabinet that’s great for rehearsals and gigs alike. It has a Solo channel with memory, eight COSM amp models, 3-band EQ, onboard effects, and a world’s first, built-in Looper for constructing stacks of sound in real-time.

• 60 W

• BASS INPUT: -10 dBu/1 M ohm
• AUX IN: -10 dBu

• 25 cm (10 inches) + Tweeter (Coaxial, 2-way)

• POWER Switch, TUNER Switch, POWER SQUEEZER Switch
• [COMP/DRIVE]
• COMP/DRIVE Knob (COMP, DRIVE)
• [COSM AMPLIFIER]
• TYPE Switch (SUPER FLAT, FLIP TOP, B MAN, T.E, BASS360, SESSION, CONCERT 810, SUPER LOW)
• SHAPE Switch
• GAIN Knob
• VOLUME Knob
• [SOLO]
• ON/OFF, MEMORY Switch
• VOLUME Knob
• [EQUALIZER]
• BASS Knob
• MIDDLE Knob
• TREBLE Knob
• [EFX]
• EFX Knob (CHORUS, POLY OCTAVE)
• [REVERB]
• REVERB Knob (ROOM, PLATE)
• [DELAY/LOOPER]
• REC/PLAY/DUB Switch
• TAP/STOP Switch
• DELAY/LOOPER Knob (DELAY, LOOPER)
• [DI OUT]
• GND LIFT Switch (OFF, ON)

• Power
• COMP/DRIVE
• TUNER
• SHAPE
• SOLO
• EFX
• DELAY/LOOPER
• REC/PLAY/DUB
• REVERB
• POWER SQUEEZER

• BASS INPUT Jack (1/4" phone type)
• AUX IN Jack (Stereo miniature phone type)
• LINE OUT Jack (1/4" phone type)
• DI OUT Jack (XLR type)
• RECORDING OUT/PHONES Jack (Stereo 1/4" phone type)
• FOOT SW Jack (TIP:SOLO, RING:COMP/DRIVE) (1/4" TRS phone type)
• FOOT SW Jack (TIP:EFX, RING:REVERB) (1/4" TRS phone type)
• FOOT SW Jack (TIP:DELAY/REC/PLAY/DUB, RING:TAP/STOP) (1/4" TRS phone type)

• 25 W

• Owner's Manual

• Footswitch (BOSS FS-5L, FS-5U, FS-6, FS-7)

421 mm (16-5/8 inches)

325 mm (12-13/16 inches)

479 mm (18-7/8 inches)

16.2 kg (35 lbs. 12 oz.)
